• مناسب برای کاربردهای HD
• حفاظت و نگهداری بالای کابل
• ساخته شده از مواد با کیفیت بالا
• مطابق با استانداردهای IEC 60803 و IEC60352-2
| مشخصات فنی Technical Specifications |
|
| Product | |
| BNC 75 Ω | Connection Type |
| Female | Gender |
| Electrical | |
| ≤ 3 mΩ (inner) | Contact resistance |
| ≤ 2 mΩ (outer) | Contact resistance |
| 1,5 kVdc | Dielectric strength |
| 75 Ω | Impedance |
| > 5 GΩ | Insulation resistance |
| <50 V | Rated voltage |
| ≤1.050/>32 dB up to 1 GHz ≤1.065/>30 dB up to 2 GHz ≤1.100/>26 dB up to 3 GHz |
VSWR |
| Mechanical | |
| 4.3 mm | Cable O.D. |
| > 30 N (Center) | Cable retention |
| 4,53 Hex (mm) crimp (shield) | Crimp size |
| 1,6 Square (mm) crimp (pin) | Crimp size (pin) |
| < 25 N | Insertion force |
| > 1000 mating cycles | Lifetime |
| Jacket crimping | Cable anchoring |
| Material | |
| Brass (CuZn35Pb2), 0.2 µm AuCo (Center contact) | Contacts |
| PTFE | Insert |
| Brass (CuZn39Pb3) | Shell |
| Optalloy® | Shell plating |
| Environmental | |
| -30 °C to +85 °C | Temperature range |
