• مقاومت بالا در برابر نفوذ آب و گرد و غبار
• دارای درجه حفاظت IP68 مطابق با IEC 60529
| مشخصات کلی General specifications |
|
| Surge Arrester | Product name |
| 7/16 Female – 7/16 Male | Type |
| 50 ohms | impedance |
| 698 to 2700 MHz | Frequency Range |
| 1.8 KW @ 1 GHz | Power handling (20 °C, sea level, VSWR 1.0) |
| 160V @ 20kA, 8/20 μs > 15V @ 4kV 1.2/50μs, 2kA 8/20 μs > |
Residual voltage |
| 25 kA (8/20 μs) | Nominal impulse discharge current |
| ≤ 0.1dB | Insertion loss |
| ≥ 21 dB, 698 to 800 MHz ≥ 26 dB, 800 to 960 MHz ≥ 21 dB, 960 to 1700 MHz ≥ 24 dB, 1700 to 2500 MHz ≥ 21 dB, 2500 to 2700 MHz |
Return Loss |
| <-160 dBc @ 2 x 43 | PIM |
| >500 | Mating cycles |
| -45°C to +85°C | Temperature range |
| IEC 61169-4, IEC 60068, IEC 60529 IP68, RoHS | Standards |
