• پشتیبانی از استانداردهای AISG 1.1 و AISG 2.0
• محدوده دمایی 40- تا 65 درجه سلسیوس
• تک بانده
| DATA | Item |
| Electrical specifications | |
| 8220.40 | Product number |
| AISG1.1 , Ericsson, 3GPP/AISG V2.0 configurable | Standard |
| +10 to +30 V | Power supply |
| <1mC | Startup surge |
| <400mA at Vin <19V, <250 mA at Vin >19V | Current consumption during tilting |
| <100mA at Vin <19V, <50mA at Vin >19V | Current consumption idle |
| 9.6 kbps | AISG data rate |
| < +/- 0.8mm | Rod positioning accuracy |
| -40 to +65° C | Operating temperature |
| Conformity with the relevant provision(s) of the directives RTTE 99/5/EG and LVD 73/23/EEG | Type approvals |
| >500.000 hrs. | MTBF |
| Mechanical Specification | |
| 1 kg | Weight |
| 125 x 213 x 62 (excluding mounting screws) |
Dimensions (W,L,H) (mm) |
| M6 screw | Connector protection ground |
| AISG IEC 60130-9 (Ed 3.0) | Connector |
| IP65 | Ingress protection |
| ETSI 300 019 | Environmental |
